baby pull-up training pants production line

main technical data

working speed(production speed)	400pcs~450pcs/minute
working speed(linear web speed)	up to 220meters/minute
power supply	380v 50hz, tri-phase
installation power capacity	380kw
air consumption	4000l/minute
qualified rate	≥98%
waist width(min~max, for training pants)	385mm
product length(min~max, for training pants)	400~550mm
dimensions(l×w×h, meters)	l: 28~30 w: 6~12 h: 3.5~4.5

technical features
compact design, easy
operation&maintenance
modular design, for future upgrading
low consumption, high efficiency
servo or frequency inverter
transmission
touch screen for man-machine
conversation
auto record and calculation of
process data
main raw material auto splicing at
zero speed
inverter or servo unwinding with
tension control
web guiding controller
sensor quality control systems
material broken and lost inspection,
auto machine stop and defective
products auto rejection
easy size changing and manufacture
ce approval

basic process configuration:
high speed pulverizer(untreated
pulp is allowed)
fluff forming unit
sap dosing unit
raw material feeding units
inner core cutter unit
inner core turning unit
waist elastics application unit
central folding unit
final cutter unit
air application unit
safety protection unit

optional process configurations:
aloe/perfume application unit
gravimetric sap dosing unit
full servo auto stacker
camera quality detection unit

raw material specifications

item number	raw material layer
1	hydrophilic n.w.(for top sheet)
2	hydrophobic n.w.(for standing cuff)
3	acquisition&distribution layer n.w.
4	fluff core pad
5	sap(super absorbent polymer)
6	upper tissue
7	lower tissue
8	back sheet pe
9	back sheet(clothlikes)
10	waist inner n.w.
11	waist outer n.w.
12	leg elastics
13	leak elastics(for standing cuff)
14	waist band
15	waist elastics
